Ball Bearing Bellevilles are used to pre-load ball bearings to reduce noise and vibration, and are ideal for absorbing axial end play. These parts can be used to pre-load either the inner or outer ring of ball bearings, and are manufactured in sizes complimentary to a range of standard ball bearing sizes.
| Part Number | Outside Diameter | Wire Diameter | Length | Rate (lbs) | Material |
|---|---|---|---|---|---|
| 36134G | 0.53 | 0.065 | 1.2 | 42.53 | HDMB |
| 36135G | 0.62 | 0.065 | 0.95 | 46.19 | HDMB |
| 36136G | 0.295 | 0.016 | 1.69 | 0.34 | HDMB |
| 36137G | 0.312 | 0.0286 | 1 | 4.8 | HDMB |
| 36138G | 0.25 | 0.02 | 1.5 | 2.1 | HDMB |
| 36139G | 0.435 | 0.034 | 2 | 2.98 | HDMB |
| 36140G | 0.323 | 0.039 | 1.755 | 5.25 | HDMB |
| 36141G | 0.61 | 0.041 | 1.44 | 3.14 | HDMB |
| 36142G | 0.707 | 0.041 | 3.31 | 1.35 | HDMB |
| 36143G | 0.407 | 0.054 | 2.75 | 12.17 | HDMB |
| Part Number | Outside Diameter | Wire Diameter | Length | Rate (N) | Material |
|---|---|---|---|---|---|
| 36134G | 13.46 | 1.65 | 30.48 | HDMB | |
| 36135G | 15.75 | 1.65 | 24.13 | HDMB | |
| 36136G | 7.49 | 0.41 | 42.85 | HDMB | |
| 36137G | 7.93 | 0.73 | 25.40 | HDMB | |
| 36138G | 6.35 | 0.51 | 38.10 | HDMB | |
| 36139G | 11.05 | 0.89 | 50.80 | HDMB | |
| 36140G | 8.20 | 0.99 | 44.58 | HDMB | |
| 36141G | 15.49 | 1.04 | 36.68 | HDMB | |
| 36142G | 17.96 | 1.04 | 84.12 | HDMB | |
| 36143G | 10.34 | 1.37 | 69.85 | HDMB |
